Descrição	D	D1	L	L1	H1	H2	G
NBLSLA436 Mandril porta barra MAS403 BT30 furo 6 mm Consultar	6	25	60	30	12	10	M-6x1,0
NBLSLA437 Mandril porta barra MAS403 BT30 furo 8 mm Consultar	8	28	60	35	14	12	M-8x1,25
NBLSLA438 Mandril porta barra MAS403 BT30 furo 10 mm Consultar	10	35	60	40	15	14	M-8x1,25
NBLSLA439 Mandril porta barra MAS403 BT30 furo 12 mm Consultar	12	42	60	50	20	16	M-12x1,5
NBLSLA440 Mandril porta barra MAS403 BT30 furo 16 mm Consultar	16	48	75	60	20	18	M-12x1,5
NBLSLA441 Mandril porta barra MAS403 BT30 furo 20 mm Consultar	20	52	75	70	23	19	M-12x1,5
NBLSLA442 Mandril porta barra MAS403 BT40 furo 6 mm Consultar	6	25	75	30	12	10	M-6x1,0
NBLSLA443 Mandril porta barra MAS403 BT40 furo 8 mm Consultar	8	28	75	35	14	12	M-8x1,25
NBLSLA444 Mandril porta barra MAS403 BT40 furo 10 mm Consultar	10	35	75	40	15	14	M-8x1,25
NBLSLA445 Mandril porta barra MAS403 BT40 furo 12 mm Consultar	12	42	75	50	20	16	M-12x1,5
NBLSLA446 Mandril porta barra MAS403 BT40 furo 14 mm Consultar	14	44	75	50	20	16	M-12x1,5
NBLSLA447 Mandril porta barra MAS403 BT40 furo 16 mm Consultar	16	48	75	60	20	18	M-12x1,5
NBLSLA448 Mandril porta barra MAS403 BT40 furo 18 mm Consultar	18	50	75	60	20	18	M-12x1,5
NBLSLA449 Mandril porta barra MAS403 BT40 furo 20 mm Consultar	20	52	90	70	23	19	M-12x1,5
NBLSLA450 Mandril porta barra MAS403 BT40 furo 25 mm Consultar	25	62	90	80	24	25	M-18x1,5
NBLSLA451 Mandril porta barra MAS403 BT40 furo 32 mm Consultar	32	63	90	80	24	28	M-20x1,5
NBLSLA452 Mandril porta barra MAS403 BT40 furo 40 mm Consultar	40	79	105	80	24	28	M-20x1,5
NBLSLA453 Mandril porta barra MAS403 BT40 furo 42 mm Consultar	42	79	105	80	24	28	M-20x1,5
NBLSLA454 Mandril porta barra MAS403 BT50 furo 6 mm Consultar	6	25	90	30	12	10	M-6x1,0
NBLSLA455 Mandril porta barra MAS403 BT50 furo 6 mm Consultar	6	25	150	30	12	10	M-6x1,0
NBLSLA456 Mandril porta barra MAS403 BT50 furo 8 mm Consultar	8	28	90	35	14	12	M-8x1,25
NBLSLA457 Mandril porta barra MAS403 BT50 furo 8 mm Consultar	8	28	150	35	14	12	M-8x1,25
NBLSLA458 Mandril porta barra MAS403 BT50 furo 10 mm Consultar	10	35	90	40	15	14	M-8x1,25
NBLSLA459 Mandril porta barra MAS403 BT50 furo 10 mm Consultar	10	35	150	40	15	14	M-8x1,25
NBLSLA460 Mandril porta barra MAS403 BT50 furo 12 mm Consultar	12	42	90	50	20	16	M-12x1,5
NBLSLA461 Mandril porta barra MAS403 BT50 furo 12 mm Consultar	12	42	150	50	20	16	M-12x1,5
NBLSLA462 Mandril porta barra MAS403 BT50 furo 14 mm Consultar	14	44	90	55	20	16	M-12x1,5
NBLSLA463 Mandril porta barra MAS403 BT50 furo 16 mm Consultar	16	48	90	60	20	18	M-12x1,5
NBLSLA464 Mandril porta barra MAS403 BT50 furo 16 mm Consultar	16	48	150	60	20	18	M-12x1,5
NBLSLA465 Mandril porta barra MAS403 BT50 furo 18 mm Consultar	18	50	90	60	20	18	M-12x1,5
NBLSLA466 Mandril porta barra MAS403 BT50 furo 20 mm Consultar	20	52	105	70	23	19	M-12x1,5
NBLSLA466-1 Mandril porta barra MAS403 BT50 furo 20 mm Consultar	20	50	90	60	20	18	M-12x1,5
NBLSLA467 Mandril porta barra MAS403 BT50 furo 20 mm Consultar	20	52	150	70	23	19	M-12x1,5
NBLSLA468 Mandril porta barra MAS403 BT50 furo 20 mm Consultar	20	52	200	70	23	19	M-12x1,5
NBLSLA470 Mandril porta barra MAS403 BT50 furo 25 mm Consultar	25	65	105	80	24	28	M-18x1,5
NBLSLA471 Mandril porta barra MAS403 BT50 furo 25 mm Consultar	25	65	150	80	24	28	M-18x1,5
NBLSLA472 Mandril porta barra MAS403 BT50 furo 25 mm Consultar	25	65	200	80	24	28	M-18x1,5
NBLSLA474 Mandril porta barra MAS403 BT50 furo 32 mm Consultar	32	72	105	80	24	28	M-20x1,5
NBLSLA477 Mandril porta barra MAS403 BT50 furo 32 mm Consultar	32	72	250	80	24	28	M-20x1,5
NBLSLA478 Mandril porta barra MAS403 BT50 furo 40 mm Consultar	40	90	120	90	30	32	M-20x1,5
NBLSLA479 Mandril porta barra MAS403 BT50 furo 42 mm Consultar	42	90	120	90	30	32	M-20x1,5

NBLSLA436 Mandril porta barra MAS403 BT30 furo 6 mm

Código:

Valor:

Detalhes do produto
