NBLOZ32211 Pinça para fresadora e cnc OZ32 Ø 16 mm |
| |
NBLOZ32211 Pinça para fresadora e cnc OZ32 Ø 16 mm
|
Código: |
NBLOZ32211 |
Valor: |
Valor sob consulta |
|
 |
|
Detalhes do produto |
Modelo | D1(mm) | L (mm) | D2 (mm) | ER-8 | 8,5 | 13,5 | 1,0 – 1,5 – 2,0 – 2,5 – 3,0 – 3,5 – 4,0 – 4,5 – 5,0 | ER-11 | 11,5 | 18 | 1,0 – 2,0 – 3,0 – 4,0 – 5,0 – 6,0 – 7,0 | ER-16 | 17 | 2 | 1,0 – 2,0 – 3,0 – 4,0 – 5,0 – 6,0 – 7,0 – 8,0 – 9,0 – 10,0 | ER-20 | 21 | 31 | 2,0 – 3,0 – 4,0 – 5,0 – 6,0 – 7,0 – 8,0 – 9,0 – 10,0 – 11,0 – 12,0 – 13,0 | ER-25 | 26 | 35 | 2,0 – 3,0 – 4,0 – 5,0 – 6,0 – 7,0 – 8,0 – 9,0 – 10,0 – 11,0 – 12,0 – 13,0 – 14,0 – 15,0 – 16,0 | ER-32 | 33 | 40 | 3,0 – 4,0 – 5,0 – 6,0 – 7,0 – 8,0 – 9,0 – 10,0 – 11,0 – 12,0 – 13,0 – 14,0 – 15,0 – 16,0 – 17,0 –18,0 – 19,0 – 20,0 | ER-40 | 41 | 46 | 4,0 – 5,0 – 6,0 – 7,0 – 8,0 – 9,0 – 10,0 – 11,0 – 12,0 – 13,0 – 14,0 – 15,0 – 16,0 – 17,0 – 18,0– 19,0 – 20,0 – 21,0 – 22,0 – 23,0 – 24,0 – 25,0 – 26,0 | ER-50 | 52 | 60 | 12,0 – 14,0 – 16,0 – 18,0 – 20,0 – 22,0 – 24,0 – 26,0 – 28,0 – 30,0 – 32,0 – 34,0 |  | OZ-25 | 35,05 | 52 | 3,0 – 4,0 – 5,0 – 6,0 – 7,0 – 8,0 – 9,0 – 10,0 – 11,0 – 12,0 – 13,0 – 14,0 – 15,0 – 16,0 – 17,0 –18,0 – 19,0 – 20,0 – 21,0 – 22,0 – 23,0 – 24,0 – 25,0 1/8” – 3/16” – 1/4" – 5/16” – 3/8” – 7/16” – 1/2" – 9/16” – 5/8” – 11/16” – 3/4" – 13/16” – 7/8” –15/16” – 1” | OZ-32 | 44 | 60 | 6,0 – 7,0 – 8,0 – 9,0 – 10,0 – 11,0 – 12,0 – 13,0 – 14,0 – 15,0 – 16,0 – 17,0 – 18,0 – 19,0 –20,0 – 21,0 – 22,0 – 23,0 – 24,0 – 25,0 – 26,0 – 27,0 – 28,0 – 29,0 – 30,0 – 31,0 – 32,0 1/4" – 5/16” – 3/8” – 7/16” – 1/2" – 9/16” – 5/8” – 11/16” – 3/4" – 13/16” – 7/8” – 15/16” – 1” –1.1/8” – 1.1/4” |
|
|
| |
|
|
|
|
 |
